DEWALT 20V MAX* XR Brushless Cordless 7-1/4 in. Circular Saw Kit
Item #:
DCS570P1
Manufacturer Item: DCS570P1
This DEWALT 20V cordless circular saw gives you with the power and depth-of-cut of a corded circular saw, but with the portability and convenience of cordless. DEWALT brushless motor technology delivers excellent performance and runtime when cross cutting 2x material and ripping sheet goods.
Features
- Power - Brushless motor provides 5500rpm and maintains speed under load
- Runtime - 330 cross cuts in a 2x4 (pine)
- Capacity - 7-1/4" Blade provides 2-9/16" depth of cut
- Ease of Use - Bevel capacity up to 57 degrees
Specifications
| Length | 15.72 in |
| Width | 12.15 in |
| Height | 11.05 in |
| Weight | 13.72 lbs |
| Power Source | Electric |
| Cordless Vs. Corded | Cordless |
| Motor Type | Brushless |
| Voltage | 20 V V |
| Battery Included | Yes |
| Battery Type | 20V MAX Lithium Ion |
| Battery Qty | 1 |
| Battery Test Summary | DEWALT_UN38.3 LITHIUM TEST SUMMARY_rev1,10.pdf |
| Battery Amp Hours | 5 Ah Ah |
| Net Lit-Ion Y/N | Yes |
| Charger Included | Yes |
| Charger Type | Jack Plug |
| Battery Required | Yes |
| Number Of Batteries Required | 1 |
| Disclaimer | Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18. |
| Hazmat | Li-IonBatt <101 WH |
| Prop 65 Generic Warning | Yes |
| Warranty | 3LW1YS90D |
| Certifications Or Listings | UL Listed |
| California Prop 65 Warning Label | http://images.salsify.com/image/upload/s--GK8MnSRs--/aq37mya9pqnhhhehoftu.pdf |
| Claims Needed | Yes |
| Hazmat Code | A1 |
| Adjustable Depth | Yes |
| App Compatibility | No |
| Arbor Size | 0.625 |
| Bevel Capacity | 57 |
| Blade Diameter | 7 1/4 in In. |
| Blade Location | Left |
| Blade Qty | 1 |
| Bluetooth Compatibility | No |
| Case Type | N/A (no case) |
| Dust Collection | No |
| Housing Material | Plastic |
| Individual Vs. Set (Syndigo) | SET |
| Integrated Laser Guide | No |
| Integrated Work Light | Yes |
| Maximum Cut Depth @ 45 Deg. | 2" |
| Maximum Cut Depth @ 90 Deg. | 2-9/16" |
| Maximum Speed | 5200 RPM Rpm |
| Saw Drive Type | Direct Drive |
| Shoe Material | Aluminum |
| Spindle Lock | No |
| Variable Speed | No |
| Wifi Compatibility | No |
| Works With Android | No |
| Works With Ios | No |
| Product Finish | Yellow/Black/Silver |
